PCB Assembly Services

Wonderful is capable of providing full turn-key PCB assembly services and Electronic Manufacturing Services.

Parts Sourcing
SMT & THT
Intelligence SMT Line
Reliable Testing
ROHS Compliant
IC Programming

Get a PCB Assembly Quote

✓ All uploaded files are secure and confidential

Our Numbers

Years in Business

1 +

Countries Served

1 +

Happy Customers

1000 +

Projects Yearly

1000 +

Machines

1000 +

㎡ Factory

100000 +

PCB Assembly Capabilites

Item #	Item Name		PCBA Capability
1.	Lead Time		Our assembly time ranges from 24 Hours to a few weeks. Please choose appropriate time option to fit your schedule and budget. Due to the complexity of how to determine the turn time of PCBA services, our policy is that turn-time begins immediately after all the parts are ready and all the PCB files (Gerber files/other PCB files, etc.,) , Centroid (Pick & Place PNP file, or XY Data or files in other formats), BOM, and all other necessary data or documents/images/photos are complete for our assembly work.
2.	Parts Source	Consigned/kitted	We prefer you supply all the parts for the PCBA services. In this case, please send us all the components with BOM file and detailed packing list indicating item number, customer or manufacturer’s part number and quantity in kit.
		Turn-key	With our wide and powerful network of parts sourcing, we offer Turn-key PCBA service. We do not mark up on the parts cost. Considering the big price gap between different suppliers, we only source from reliable suppliers who may have no price advantages. We will always ask for your approval before making any decisions.
		Partial Turn-key/Combo	This is our regular practice which you offer the main devices and components, while we source the rest for you. Just like the Turn-key service, we will ask for your approval on every details of the parts concerning price, quality and availability.
3.	Assembly Options		Surface mount Thro-hole Mixed technology (SMT & Thru-hole) Single or double sided placement Conformal coating Shield cover assembly for EMI emission control
4.	Types of Solder		We offer both leaded and lead-free (RoHS Compliant) assembly services for our customers. Please choose one to best fit your PCB and the parts on the PCB.
5.	Stencils		We use laser cut stainless steel stencils to ensure high reliability for fine pitch and BGA components. Nano coating is available upon request.
6.	Minimum Order		Our minimum is as low as 5 pieces. We do not want you to pay for what you do not need indeed to save you money.
7.	Component Size		Passive Component: we can accept components as small as 01005, 0201,0402. BGA: We have the ability to handle BGA of 0.3mm pitch for rigid PCBs and 0.4mm for flex boards with X-ray testing. (The details can be confirmed according to the board design.) Fine Pitch Parts: we can assemble 0.25mm fine pitch parts.
8.	Component Package		Reels, Cut Tape, Tube & Tray, Loose Parts and Bulk.
9.	Board Dimension		Min Board Size: 10mm x 10mm (Boards smaller than this size need to be panelized) Max Board Size: 250mm x 500mm
10.	Board Shape		We can assemble boards in Rectangular, Circular and any Odd Shapes. (For shapes other than rectangle, you need to panelize the boards in an array, and add break-away rails at the two longer paralleled edges of the panelized boards to ensure that the boards can be assembled by the machine.)
11.	Board Type		Currently we handles Rigid boards mostly. As we have the ability to handle flex and rigid-flex boards, please contact [email protected] if your boards are of flex or rigid-flex.
12.	Repair & Rework		Repair and rework can be difficult, but we do. Our BGA reballing service with which we can safely remove the misplaced BGA, reball it and put it back on the PCB correctly. It is cost-effective.

PCB Assembly Process Flowchart

Wonderful PCB Provide SMT and DIP Plugin(THT) assembly services, including wave soldering, backward welding, reflow soldering, cleaning, test and QC, QA, etc.
